DW-28CNC-4A-2S
Servo-driven Full Automatic CNC Pipe Bending Machine
Key Features
Technical Specifications
Detailed technical parameters for DW-28CNC-4A-2S
| Model | DW-28CNC-4A-2S |
| Max Tube O.D. Bending Capacity | Φ28mm |
| Max Tube Wall Thickness | 2.0mm |
| CLR Range (Customizable) | 100mm |
| Max Bending Angle | 190° |
| Max Mandrel Working Distance | 2000mm |
| Tube Feeding Speed | Max 1000mm/s |
| Tube Rotation Speed | Max 200°/s |
| Tube Bending Speed | Max 85°/s |
| Tube Feeding Precision | ±0.1mm |
| Tube Rotation Precision | ±0.1° |
| Tube Bending Precision | ±0.1° |
| Machine Dimensions (L×W×H) | 3000×780×1100mm |
| Overall Weight | Approx. 1000kg |
* Specifications subject to change without notice due to continuous R&D improvement.
Product Description
The DW-28CNC-4A-2S is a state-of-the-art full automatic CNC pipe bending machine designed for high-precision, high-efficiency tube bending operations. Featuring servo-driven feeding system and 4-axis simultaneous control, this machine delivers exceptional accuracy and repeatability.
Equipped with 2 stack bending dies, it enables multiple radius bending without changing tools, significantly improving production efficiency. The advanced CNC control system with touch screen interface allows easy programming and operation.
Ideal for automotive, HVAC, furniture, fitness equipment, and other industries requiring precise tube bending. The machine supports OEM/ODM customization to meet specific production requirements.
